Quick Details

  • Application: Laser Cutting
  • Condition: New
  • Laser Type: CO2
  • Applicable Material: Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
  • Cutting Thickness: 0~30mm
  • Cutting Area: 1300*2500mm
  • Cutting Speed: 0~4500mm/min
  • CNC or Not: Yes
  • Cooling Mode: Water Cooling
  • Control Software: RUIDA
  • Graphic Format Supported: AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: RODEO
  • Model Number: RDJ-1325
  • Certification: CE, ISO
  • After-sales Service Provided: Overseas service center available
  • Name: cnc laser cutting machine
  • Laser power: 80W/100W/150W/180W
  • Cutting area: 1300mm*2500mm
  • Cutting table: Strip panel working table
  • Engraving(no-load)speed: 0-60000mm/min
  • Repeating location: ≤0.01mm
  • Moving system: Servo moving system
  • Cooling system: Constant temperature water chiller for laser machine
  • Power supply: AC220V±5% / 50HZ
  • Format support: AI,BMP,PLT,DXF,DST etc

Packaging & Delivery

Packaging Details: Wooden cases
Delivery Detail: 7-15 days after payment
CO2 Laser Cutting Machine 1300*2500mm 1325,companies looking for distributors 180w

 metal cutting machine

Metal and non-metal laser cutting machine/laser cutting machine/laser cutter/laser cutting machine/metal laser cuttingmachine

1. Metal and non-metal laser engraving and cutting machine:

 metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

 1).Equipped with imported dual linear guide,so machine can move stably and cut the edge smoothly

 2).Powerful compatibility: Internationalized directives ensure that it is compatible with CAD/CAM software like type3/ artcam/ castmate/ proe/ UG/ artcut etc. home and abroad.

   metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

2. laser engraving and cutting machine Applicable Industries:

 metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

Widely used in the line of advertising board, Sheetmetal structure, high and low Voltage elictric cupboard industry, spare parts of the textile machines, hardware, metal handicraft article, kitchen wares, cars, machines, elevators, spare parts of the elictric devices, spring pieces, spare parts of the subway and so on.

 metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

3. laser engraving and cutting machine Applicable Materials:

 metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

Non-metal materials such as double color boards, acrylic, glass, crystal, wood, foam, bamboo, rubber, plastic, garments, paper, leather, marble, granite, tiles and etc.

Metal such as carbon steel, stainless steel,aluminium, brass

   metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

 4.Cutting thickness for diffierent materials:

   metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

1. For carbon (mild) steel: 0.2mm-8mm



2. For stainless steel: 0.1mm-4mm



3. For Aluminium: 0.1mm-2mm



4. For brass: 0.1mm-2mm

   metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

5. laser engraving and cutting machine Options:

1) Motorized up&down platform

2) Rotary attachment

3) Chiller(CW-5200 or CW-3000)

4) Auto focus

5) CCD for logo/lable

   metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

6. Metal laser engraving and cutting machine Specifications:

 metal and non-metal laser cutting machine/laser cutting machine/metal and non-metal

1)

Laser-type

Sealed CO2 laser tube, water-cooling, 10.6um

2)

Laser tube of power

130W/150W/180w

3)

Working area

1300 x2500mm

4)

Max moving speed

0-60,000mm/min

5)

Max cutting speed

0-30,000mm/min

6)

Laser output control

1-100% software setting

7)

Location precision

less than 0.01mm

8)

Highest scanning

precision: 2500DPI

9)

Operating

temperature: 0-45 degrees Celsius

10)

Operating humidity

5- 95%

11)

 Minimum shaping character

English 1.0 x 1.0mm, Chinese 2.0x2.0mm

12)

Graphic format supported

BMP, PLT, DST, DXF, and AI

13)

Driving system

stepper

14)

Cooling mode

water-cooling and protection system

15)

Auxiliary equipments

Exhaust-fans, air-exhaust pipe, water pump

16)

Controlling software

DSP control system.

17)

Compatible Software

TAJIMA , CorelDraw, AutoCAD, Photoshop

18)

Color separation

Yes









machine parts





Sample

  Packed in export



Guarantee & After-Sales Service

  laser cutting machine price/laser cutting machine/laser engraving machine/laser cutting machine price

A. One year warranty under normal use and we give maintenance for life for free.
B. 24hours technical support by phone, e-mail or MSN or Remote Assistance.
C.Free training to make sure you master the operation of cnc router
